Described electric generator contradicting the Law of Energy Conservation. Its output of electric energy is 4 times higher than the input energy. This is the discovery of a new law in physics. The therewith produced electric energy will be of benefit for humanity. The global environment will be free of air pollution. This patent could be used everywhere, idustry, spedition, for various devices, machines, vehicles and equipment for common life across the entire human culture.
Link to patents.google.com here..
Link to DEPATISnet here..
Link to freepatentsonline.com here..
The present invention relates to an electric generator consisting of two induction coils and an exciter coil, whereby the induction coils are wrapped around a two-polar magnet made of ferrous magnetic material and the exciter coil is wrapped around the two sides from the outside. The two induction coils are wrapped around the magnet core of copper wire in a known way. The exciter coil is wrapped around the two-sided core and runs from a band condenser with capacitor resistance from the outside. This invention describes a physical process, the function of which is connected to self-induction.
As per technological standards, the electric generator is a machine that transforms mechanical to electrical energy. Its functionality is based on the Law of Induction, according to which the pressure induced is proportional to the device from the coil number and the change speed of the magnetic field. Multiple technical alternatives of the generator have been constructed based on this principle of physics.
The invention was conceived in a simple technical device and consists of known components, which do not move. The generator is static. The physical process is unknown and is of immense cognitive importance for humanity. Electrical energy in terms of the mass-energy relationship has a mathematical and physical definition that is different from the one Einstein wrote about in his works.
The invention aims to create a device to implementation of a physical process, in which electrical energy is usable through induction in two magnetically connected induction coils.
The means of attaining this goal consist of two induction coils and an exciter coil as well as a bilateral core made of soft magnetic material.
This new structure (means) will be clarified further by means of presentation of examples.
Fig. 1 shows a lateral view of a generator with two induction coils and an exciter coil as well as a bilateral core made of soft magnetic material.
Fig. 2 shows a lateral view of a band condenser.
Fig. 3 shows a lateral view of exciter wrapping with two parallel ducts and two condensers.
The physical basis of this invention is portrayed in Fig. 1. The bilateral magnetic core 1 consists of soft magnetic material. The first induction coil 2 is connected to the first side 1a and the second induction coil 3 is connected to the second side 1b. Exciter coil 4 is wrapped around the two sides 1a and 1b. The magnetic field lines 5 of exciter coil 4 are outside magnetic core 1. The magnetic field lines 6, 7 of induction coils 2, 3 are connected to the inside of induction coils 2, 3. The electric connection 8 connects induction coil 2 with an electrical charge, which is not shown. The electric connection 9 links induction coil 3 to an electrical charge, which is also not shown.
Fig. 2 shows the band condenser 10 as it is illustrated in DE 199 27 355 A1. The dielectric 11 is located between metal foils 12, 13. Electric insulator 14 is above the structure. Metal foils 12 and 13 are in the middle of electrical connections 15 and 16, connected to pressure source 17. In such a circuit, the displacement current flows via dielectric 11 into the entire length of capacitor 10.
Fig. 3 shows the winding known for electric motors, transformers and electromagnets patented in June 2009 and published internationally in WO 2010/00 33 94 A2. Fig. 3 shows the principle of this winding, which consists of two metal ducts 18, 19 and two capacitors 20, 21 connected between the metal ducts 18, 19. Everything is connected to the oscillating pressure source 24 via electrical connections 22, 23.
The invention described here is an electric generator which is technically simple and easy to understand from a physical point of view, consisting of known parts which are not movable and resembles a transformer. The magnetic core 1 is bilateral and made of soft magnetic material. In the case of induction, magnetic field 6 of coil 2 is in polarity against magnetic field 7 of coil 3. The exciter coil 4 is wrapped around magnet core 1 from the outside. The electric current in exciter coil 4 generates a weak magnetic field within the magnet core 1 and causes induction in the coils 2, 3. Thereafter, electrical voltage and current in coil 3 are induced through magnetic field 6 of coil 2. At the same time, magnetic field 7 of coil 3 induces electrical voltage and current in coil 2. This is the physical novelty of this invention. Self-induction is theoretically divided in two parts in the generator described here. Induction coil 2 works with its magnetic field against the magnetic field of induction coil 3 and vice versa. The functioning of this physical process will be used throughout the global economy. The induced voltage and the current in both induction coils 2, 3 rise simultaneously in each half period.
It is experimentally obvious to prove that the power in exciter coil 4 is reactive current i.e. the power factor cos Phi is in the range of 0.1. Further, the factor cos Phi in both induction coils 2 and 3 is in the range of 0.9. This means that through the reactive current oscillation in the capacitor winding in exciter coil 4 induces active power in induction coils 2, 3.
The physical function of the product described here is, according to the current state of knowledge in physics, a puzzle that cannot be fully solved polemically. This can only be done experimentally. An experimental prototype is easy and inexpensive to make in an electric facility. Corresponding measurements prove that the invention described herein is scientifically accurate.
